A High-Frequency PCB Requires the Use of Specialized Materials

Special materials are required to achieve the high frequency provided by this type of printed circuit board – any changes in the Er value of these materials can affect the impedance of the board. Many PCB designers turn to Rogers dielectric material for its lower dielectric loss, reduced signal loss, lower cost of circuit fabrication and better suitability for fast-turnaround prototyping applications.

Apart from choosing the appropriate PCB material and determining the correct the value of the Er, designers should take parameter such as conductor width and spacing, substrate constant into consideration. These parameters must be exactly specified and implemented with the highest level of process control.

We’re a High-Frequency PCB Manufacturer That Takes the Time to Assess Your Needs

Assemblepcb is an experienced full service PCB manufacturer who provides a reliable, superior-performing high-frequency PCB fabrication services.

We manufacture high-frequency PCBs with frequency typically in the range from 500MHz to 2GHz. The following table shows some of our common-use materials for High-Frequency PCBs manufacturing.

Check our capabilities by viewing the table found below:

Discuss your High Frequency PCB Project Today

For High Frequency PCB manufacturing price, please send your PCB file (Gerber format preferred | Preorder Checklist), we’ll quote at quickest speed.

Wanna know our customizable high-frequency PCB solutions? Can’t determine which PCB material is the best choice for your project? Please feel free to contact us for practical solutions.
