Images
Mfr.Part #
In Stock
Manufacturer
Description
Package
X66AK2H06AAAW24 X66AK2H06AAAW24 19035 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06AAWA2 X66AK2H06AAWA2 47607 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06AXAAW2 X66AK2H06AXAAW2 35290 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
TMS320C6743DPTPT3 TMS320C6743DPTPT3 29033 Texas Instruments IC DSP FIX/FLOAT POINT 176HLQFP 176-LQFP Exposed Pad
X66AK2H12AAAW24 X66AK2H12AAAW24 49820 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06AAW2 X66AK2H06AAW2 6187 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
TMS320DM8127BCYE3 TMS320DM8127BCYE3 21094 Texas Instruments IC DGTL MEDIA PROCESSR 684FCBGA 684-BFBGA, FCBGA
X66AK2H12AAAWA24 X66AK2H12AAAWA24 46694 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06XAAW2 X66AK2H06XAAW2 20043 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06AAAWA24 X66AK2H06AAAWA24 38918 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
TMS320DM8127BCYE1 TMS320DM8127BCYE1 10261 Texas Instruments IC DGTL MEDIA PROCESSR 684FCBGA 684-BFBGA, FCBGA
TMS320DM8127BCYED1 TMS320DM8127BCYED1 19744 Texas Instruments IC DGTL MEDIA PROCESSR 684FCBGA 684-BFBGA, FCBGA
X66AK2H06AAAW2 X66AK2H06AAAW2 35391 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
TMS320DM8165SCYG4 TMS320DM8165SCYG4 10439 Texas Instruments IC DGTL MEDIA PROCESSR 1031FCBGA 1031-BFBGA, FCBGA
X66AK2H12AAAWA2 X66AK2H12AAAWA2 16484 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
X66AK2H06AAWA24 X66AK2H06AAWA24 19012 Texas Instruments IC DSP ARM SOC BGA 1517-BBGA, FCBGA
TMS320DM8167SCYG4 TMS320DM8167SCYG4 25217 Texas Instruments IC DGTL MEDIA PROCESSR 1031FCBGA 1031-BFBGA, FCBGA
TMS320DM8169BCYG4 TMS320DM8169BCYG4 7197 Texas Instruments IC DGTL MEDIA PROCESSR 1031FCBGA 1031-BFBGA, FCBGA
TMS320DM8127BCYE0 TMS320DM8127BCYE0 41527 Texas Instruments IC DGTL MEDIA PROCESSR 684FCBGA 684-BFBGA, FCBGA
TMS320DM8147BCYE2 TMS320DM8147BCYE2 25892 Texas Instruments IC DGTL MEDIA PROCESSR 684FCBGA 684-BFBGA, FCBGA

DSP (Digital Signal Processors)

1. What are DSP (Digital Signal Processors)?‌

‌DSP (Digital Signal Processor)‌ is a microprocessor designed for high-speed digital signal processing algorithms. It performs filtering, compression, enhancement, and other operations by processing the digital sequence converted from analog signals in real-time. It is widely used in communications, medicine, consumer electronics, and other fields. Its essence is to process real signals in digital form to extract and convert information.



2. What are the ‌Core Hardware Features of DSP (Digital Signal Processors)?‌

‌Harvard Structure

The program and data storage space are independent, supporting parallel execution of instruction reading and data operations, significantly improving throughput efficiency.



‌Dedicated Hardware Acceleration Unit

Built-in hardware multiplier (MAC), single-cycle multiplication and addition operations, suitable for intensive calculations such as matrix operations and Fourier transforms.



Multi-address generator reduces memory access bottlenecks.



‌Pipeline Technology

Instructions are decomposed into multi-stage parallel processing such as instruction fetch, decoding, and execution to achieve efficient pipeline operations.



‌Low-latency Response

Fast interrupt processing and hardware I/O support to meet scenarios with high real-time requirements (such as industrial control).



3. What are the ‌Typical Application Scenarios of DSP (Digital Signal Processors)?‌

1) ‌Communications‌

Processing fiber dispersion and polarization interference in optical communications to achieve signal recovery and equalization.



2) ‌Consumer Electronics‌

Audio Processing: frequency division management, delay correction, and EQ adjustment of car audio (such as DSP amplifier);

Wearable Devices: For example, the ATS3085L chip of Actions Technology equipped with an Honor bracelet realizes health monitoring and low-power operation through MCU+DSP dual-core heterogeneous design.



3) ‌Embedded System‌

Combined with SBC (single-board computer) to enhance data processing capabilities, used for complex tasks such as aerospace and industrial control.



4) ‌Image and Automation‌

The advantages of floating-point operations and matrix processing are suitable for machine vision, motor control, etc.



4. ‌Technology Evolution and Trends of DSP (Digital Signal Processors)‌

‌Heterogeneous Integration‌: Modern DSPs are often combined with MCU/ARM cores (such as TI J6/J7), taking into account general computing and special processing capabilities.

‌Energy Efficiency Optimization‌: Low power consumption design promotes its penetration in the Internet of Things and wearable devices (such as Actions chip power consumption <150μA).



5. ‌Summary‌

DSP has become the core device of digital technology with its customized hardware architecture and real-time processing capabilities, covering all scenarios from high-end communication equipment to daily consumer electronics, and continuously promoting the innovation of signal processing technology.



6. DSP (Digital Signal Processors) FAQs

1) ‌How to deal with excessive power ripple? ‌

Adding capacitor filtering can effectively suppress power ripple while ensuring that the reference power supply and analog power supply are pure.



2) ‌Is the external crystal oscillator active or passive? ‌

It is recommended to use a passive crystal rather than an active crystal oscillator to ensure clock stability.



3) ‌Multi-DSP system clock synchronization solution? ‌

Use a dedicated clock chip to unify the clock source to avoid timing confusion.



4) ‌A/D conversion accuracy assurance measures? ‌

It is necessary to independently purify the analog power supply and reference power supply to reduce noise interference.
